ULTRA NXT 3" Square LED Flood Lamp – 4,800 Lumens

A compact 3" square LED flood lamp on an adjustable mount, from the Uni-Bond ULTRA NXT series. 4 × 10 W LEDs produce 4,800 raw lumens (3,110–1,810 effective) with 530 ft of optimal penetration. Runs on 12–30 V, drawing 3.4 A at 12 V. Black aluminum housing, polycarbonate lens and IP68 & IP69K protection.

  • 4,800 raw lumens (3,110–1,810 effective) · flood beam · 530 ft optimal penetration
  • 12 V – 30 V input · 3.4 A @ 12 V draw
  • Sealed Deutsch Connector
  • Adjustable Mounts Allow for Flexible Aiming of Beam
  • Brackets & Hardware Included
  • Pressure Relief Vent
  • Electronic Thermal Management (ETM)
  • Plug-and-go: pair two lamps with the PT6812 Plug & Go Harness (dual-lamp, sold separately)
  • IP68 & IP69K · CE · RoHS
$ 80.24 $ 80.24
$ 80.24

FKR SALES – on hand
Special order — Available to order
Delivery & store pickup
Available to order (special order)
Add to cart
Terms and Conditions
Ships within 2 business days
Contact Us

Internal Reference: LW0328

Specifications

Raw Lumens4,800 lm
Effective Lumens3,110 – 1,810 lm
Optimal Penetration530 ft
LEDs4 × 10 W
Beam PatternFlood

Operating Voltage12 V – 30 V
Amp Draw3.4 A @ 12 V
ConnectorSealed Deutsch
Plug & Go HarnessPT6812 (dual-lamp, sold separately)

HousingBlack Aluminum
LensPolycarbonate
VentingPressure relief vent
Thermal ProtectionElectronic Thermal Management

Size3.17" W × 3.25" H × 3" D
80.5 W × 82.5 H × 76.2 D mm

Ingress ProtectionIP68 & IP69K
EMCCE
RoHSCertified

Part NumberLW0328
BrandUni-Bond Lighting
SeriesULTRA NXT
ApplicationOff-road
PackagingBox

Specifications from Uni-Bond Lighting. Metric dimensions converted from inches.

What’s in the Box

  • 1 × LW0328 3" Square LED Flood Lamp
  • Brackets & hardware

Wiring

Sealed Deutsch. For a plug-and-go install, pair two lamps with the Uni-Bond PT6812 Plug & Go Harness (dual-lamp harness, sold separately).

Application

Off-road.
